MPO VFL Tester
GRANDWAY
MPO VFL Tester support 12 cores MPO fiber or 24 cores MPO fiber, can detect the MPO fiber sequence and continuity.
DATASHEET
SOFTWARE
MANUAL
CERTIFICATE
3.5 inch screen display
Support multiple working modes, including full red light on, individual red light on, flashing mode
Support 12 cores MPO fiber or 24 cores MPO fiber
Can detect the MPO fiber sequence and continuity
Foot pedal control is optional
| ltems | Specifications |
|---|---|
| Wavelength | 650nm±10nm |
| Optical port | MPO APC male(Customizable UPC) |
| Optical channel | 12 or 24 |
| Applicable fiber types | SM/MM |
| Battery | Rechargeable lithium battery |
| Working hours | 6 hours |
| Charging interface | USB type-C |
| Size | 44x165x44mm |
| Weight | 0.5kg |
