F2H-FOSC-BDH-Q7S24-15 Series Closure
F2H-FOSC-BDH-Q7S24-15 Series Enclosure is a heat-shrinkable dome type optical cable connector box for continuous, divergent, wiring, and storage of optical cable. It is suitable for wall mounting, aerial, and underground installation.
DATASHEET
SOFTWARE
MANUAL
CERTIFICATE
1.Water-proof design with IP65 Protection level
2.Integrated with splice cassette and cable management system
3.Manage fibers in a reasonable fiber radius condition
4.Easy to maintain and extend the capacity
5.Fiber bend radius control more than 40mm
6.The sealing mode is heat shrinkable sealing
7. 6 round ports and 1 oval uncut cable ports
